Xylem systems genetics analysis reveals a key regulator of lignin biosynthesis in Populus deltoides

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Figure 1.
Figure 1.

Characterization of eQTL associations. (A) Expression variance explained by all SNPs for each gene. (B) Number of associated genes per SNP in significant eQTL associations. (C) The distribution of genes regulated by local and/or distant SNPs. (D) Broad sense heritability for genes with and without significant eQTL associations. (E) Genomic location of SNPs with significant eQTL associations. Promoters are defined as 500 bp upstream of the gene. Data were analyzed using Kruskal–Wallis test followed by Dunn's multiple comparison test. Significance is indicated by asterisks: (****) P-value < 0.0001.

This Article

  1. Published in Advance August 19, 2020, doi: 10.1101/gr.261438.120 Genome Res. 30: 1131-1143
