A novel testis ubiquitin-binding protein gene arose by exon shuffling in hominoids

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Figure 5.
Figure 5.

Intracellular localization of GFP-fused PIP5K1A, S5a, and PIPSL proteins in 293T cells was observed by GFP fluorescence with confocal microscopy. (A) GFP control is seen throughout the cell, with nuclear predominance; (B) PIP5K1A is on the plasma membrane. (C) S5a is throughout the cell with cytoplasmic predominance and possibly nucleolar exclusion; (D) Human and (E) chimpanzee PIPSL proteins are cytoplasmic. A Western of IP’d GFP fusion proteins is shown in Supplemental Figure S6B.

This Article

  1. Published in Advance July 10, 2007, doi: 10.1101/gr.6252107 Genome Res. 17: 1129-1138
