Genomic clusters, putative pathogen recognition molecules, and antimicrobial genes are induced by infection of C. elegans with M. nematophilum

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Figure 2.
Figure 2.

Expression of the C-type lectin gene clec-60. A promoter fusion, clec-60p::GFP, was expressed in adults in the posterior intestine cells, int-8 (i8) and int-9 (i9) on both OP50 (A) and MBL plates (B,C). The variation in the intensity and extent of the GFP signal within infected worms is evident in B and C. (D) RT–PCR experiment showing F21C10.10 and clec-60 (top bands) expression compared with ama-1 (control, bottom band a) in uninfected (U) and infected (I) worms.

This Article

  1. Published in Advance June 29, 2006, doi: 10.1101/gr.50823006 Genome Res. 16: 1005-1016
